General Info:
Year: 2007
Flag: Brazilian
Builder: Aker Promar S.A. - Rio de Janeiro
Design: UT 755L
Class society ABS
Class notation: +A1; Rec-oil; Vessel Class 2; +AMS; +ACCU; DP1; FiFi1
IMO number: 9357169
Main Particulars:
Length: OA 71,90 mt
DWT: 3.222 T
Length BPP: 66,80 mt
Breadth moulded: 16,00 mt
Depth moulded: 7,00 mt
Gross tonnage: 2.143 T
Net tonnage: 796 T
Maximum draft: 5,00 mt
Machinery / Propulsion:
Main Engines: 2 x WARTSILA 8L26 - 2.480 kW each
Drive type (Direct/Diesel Electric): Direct
Total power (BHP): 6.800
Rudders: 2 x Ulstein High Lift Spade
Bow thruster(s) (number and BHP): 2 x tunnel Kamewa-Ulstein TT1650 - 590kW
Shaft generator: 2 x 1.800 kVA - 440V - 60HZ at 1.800rpm
Diesel generator: 2 x 325 kW - 440V - 60HZ
Emergency generator: 160 kVA - 440V - 60HZ
Fuel type - (MGO / IFO / HFO): MGO
Cargo Capacities:
Working Clear Deck - space: 685 sqm
Working Clear Deck - length x breadth: 51mt x 13,50mt
Max Deck Cargo: 1.500 T
Deck loading: 5T/sqm
Fuel Oil: 318 cbm
Fresh Water: 158 cbm
Drill Water: multipurpose 1.728 cbm
Mud: multipurpose 493 cbm
Dry Bulk: 256 cbm
Number of Dry Bulk tanks: 4
Cargo Discharge Capacity:
Fuel Oil: 2 x cbm/hr at 18 bar
Fresh Water: 2 x 90 cbm/hr at 9 bar
Drill Water: 200 cbm/hr at 9 bar
Mud 2 x cbm/hr at 18 bar
Speed / Consumption:
Max Speed/Consumption: 14,5 knots per 22 t/day
Economical Speed/Consumption: 10 knots per 12 t/day
Port Consumption: 0,5 t/day
Accomodation:
Crew: 10 single cabins + 3 x 2 bed cabins
Passengers: 3 x 4 cabins
FiFi:
FiFi 1
Number of monitors: 2 x 1.200 cbm/hr
Number of pumps: 2 x 1.600 cbm/hr - 14 bar
Anti Pollution Equipment:
Dispersant: 10 cbm
Spray booms: 2
Oil Recovery capacity: not dedicated - 1.571 cbm
Rescue Equipment:
Rescue Zone: Yes
Rescue Boat: 1 x 6persons - Viking 470 GRP 1
Inflatable life rafts: 6 - 96 persons in total
Life jackets:34
Navigation and Communication Equipment:
DP: Class1
DP type: Kongsberg SDP11
Radar:(number and type) Furuno - X band - S band
GMDSS: 3 x VHF GMDSS Jotron TR20
Inmarsat: 2 x Furuno Felcom 15
VHF: 3 x Furuno FM8500
DGPS/GPS: 2 x Kongsberg Seatex DPS 200 +
Furuno: GP90
Echo sounder: Furuno FE700
Speed log:2 x Furuno DS830 and DS50
Radio Telex: Furuno Fax-208 Mark-2
Gyroscopic compass:2 x Raytheon SPD22
